SR6 Series stainless steel extra-large flow pressure regulator

Home / Products / Stainless Steel Pressure Regulator / SR6 Series stainless steel extra-large flow pressure regulator

SR6 Series stainless steel extra-large flow pressure regulator

Designed specifically for industrial-grade high-volume applications, the SR6 boasts an astonishing CV value of 5.1, representing the pinnacle of flow capacity in the entire SR series. To support such high flow rates, its inlet and outlet ports are uniformly 3/4" NPT(F), utilizing nitrile rubber as the valve seat material and a composite diaphragm lined with nylon, ensuring excellent sealing resilience while maintaining ultra-high flow rates. Its overall weight of 6kg makes it a stable node in the system, capable of withstanding impacts of 1.5 times the maximum input pressure, and it is widely used in large-scale process control systems and gas manifolds in the petrochemical industry.

  • Description
  • Contact Us

Series

Bosy Ports

Inlet Pressure

Outlet Pressure

Gauge

Inlet connector

Outlet Connector

SR6

B

F

G

G

06

06

SR6L

(316L)

SR6B

(Copper electroplating)

A

B

D

G

F:500psi

G:0-250psi

H:0-125psi

1:0-100psi

K:0-50psi

L:0-25psi

G: MPa table

P: Psi/bar table

W: No pressure gauge

06:3/4"NPT(F)

07:3/4"NPT(M)

08:1"NPT(F)

09:1"NPT(M)

Other forms of connectors are available for selection

06:3/4"NPT(F)

07:3/4"NPT(M)

08:1"NPT(F)

09:1"NPT(M)

Other forms of connectors are available for selection
