SR3 Series stainless steel large flow pressure regulator

Home / Products / Stainless Steel Pressure Regulator / SR3 Series stainless steel large flow pressure regulator

SR3 Series stainless steel large flow pressure regulator

The SR3 is the "powerhouse" contender in the SR series, featuring upgraded inlet and outlet ports of 3/4" NPT(F) and a high CV value of 1.8, specifically developed for large-scale industrial gas distribution systems. Despite its significantly enhanced flow capacity, it retains the high precision of its single-stage diaphragm design. The stainless steel diaphragm accurately converts complex inlet pressures into a constant output flow, making it suitable for large-area purging of pure gases or petrochemical production lines. Its heavy-duty 2.7kg body is equipped with a dedicated safety valve port, combined with a Hastelloy diaphragm, giving it industry-leading durability when handling large flows of corrosive gases.

  • Description
  • Contact Us

Series

Body Pots

Inlet Pressure

Outlet Pressure

Gauge

Inlet connector

Outlet Connector

Options

SR3

B

E

H

G

05

05

P

SR3L

(316L)

SR3B

(Copper electroplating)

A

B

G

J

M

D:3000psi

F:500psi

H:0-125psi

J:0-75psi

L:0-25psi

M:0-15psi

Q:30"HgVao-30psi

S:30"HgVac-60psi

T:30"HgVac-100psi

G: MPa table

P: Psi/bar table

W: No pressure gauge

04:1/2"NPT(F)

05:1/2NPT(M)

06:3/4NPT(F)

13: 1/2 "card sleeve connector

14: 3/4 "card sleeve connector

Other forms of connectors are available for selection

04:1/2"NPT(F)

05:1/2NPT(M)

06:3/4NPT(F)

13: 1/2 "card sleeve connector

14: 3/4 "card sleeve connector

Other forms of connectors are available for selection

P: Panel installation

R: Safety valve
