SR1 Series Stainless Steel Small Flow Pressure Regulator

Home / Products / Stainless Steel Pressure Regulator / SR1 Series Stainless Steel Small Flow Pressure Regulator

SR1 Series Stainless Steel Small Flow Pressure Regulator

The SR1 employs a precision single-stage diaphragm pressure-reducing structure, ensuring extremely stable output pressure through pressure transmission via a high-performance stainless steel diaphragm. It can confidently handle various high-purity, corrosive, and toxic gases. The valve body is constructed from premium 316L stainless steel, the seat is made of PCTFE or PTFE, and the diaphragm is made of Hastelloy or 316L stainless steel. This advanced material combination allows it to perform exceptionally well in harsh temperatures ranging from -40°C to 74°C. Its technical parameters are highly competitive, with a CV value precisely controlled at 0.08. A 1.5 times maximum input pressure safety margin provides a solid guarantee for long-term operation in high-pressure environments, and its lightweight 0.9kg design allows for flexible panel or wall mounting.

  • Description
  • Contact Us

Series

Body Ports

Inlet Pressure

Outlet Pressure

Gauge

Inlet connector

Outlet Connector

Options

SR1

B

D

F

G

00

00

P

SR1L

(316L)

SR1B

(Steel electroplating)

A

B

D

G

J

M

Q

C:4000psi

D:3000psi

F:500psi

F:0-500psi

G:0-250psi

1:0-100psi

K:0-50psi

L:0-25psi

Q:30'HgVac-30psi

S:30'HgVac-60psi

T:30"HgVac-100psi

U:30"HgVac-200psi

G: MPa table

P: Psi/bar table

W: No pressure gauge

00:1/4"NPT(F)

01:1/4"NPT(M)

23:CGA330

24:CGA350

27:CGA580

28:CGA660

30:CGA590

52:G5/8"-RH(F)

63:W21.8-14RH(F)

64:W21.8-14LH(F)

Other forms of connectors are available

choice

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8 "card sleeve connector

11: 1/4 "card sleeve connector

12: 3/8 "card sleeve connector

15: 6mm card sleeve connector

16: 8mm card sleeve connector

74:M8x1RH(M)

Other forms of connectors are available

Choice

P: Panel installation

R: Safety valve

N: Needle valve

D: Diaphragm valve
