The NB-KSL has produced high-quality tube and pipe fittings in various materials for high-pressure applications since its establishment in 2010.
As a result of tremendous efforts in research and development during the last 3 years, NB-KSL has gained an excellent reputation as a leading manufacturer of high-pressure instrumentation Products.
The NB-KSL range of connectors has been developed to fill the rapidly increasing demand for tube fittings suitable for high-pressure use in environments such as petrochemical, fluid, power, nuclear, electronic, as well as other major industrial fields.
NB-K5L tube fittings have been carefully manufactured to withstand the persistent demands for high-performance tube fittings. Each one has passed a stringent tolerance test for high
pressure, impulse, vibration, vacuum and temperature. These precision-machined fittings are manufactured to exacting standards, employing the most modern state of-the-art computerized automation. All NB-KSE” fittings are backed by NB-KSL commitment to the highest quality-control standards
and skilled craftsmanship.
The NB-KSL tube fitting is a mechanism used both to seal and to grip tubing. The mechanical advantage and geometry of this kind of fitting produces a leak-tight assembly.
To assemble, simply insert the tube into the complete assembly until the tube bottoms out against the shoulder of the fitting body. The two ferrules are driven forward between the nut and fitting body using the mechanical force created by rotating the nut clockwise. The back ferrule is driven against the tapered rear of the front ferrule and the front ferrule is driven by force into the tapered mouth of the body.
The rear ferrule is swaged radially inwards on the tube while lifting the front ferrule out to form a full-faced seal on the tapered surface of the body.
The 1-1 / 4 turn of the nut from the hand-tight position assures consistent drive of the sealing members. This ensures an effective seal against high pressure as well as ultra high vacuum conditions.
