SR7 Series stainless steel back pressure valve

The SR7 functions completely differently from ordinary pressure regulators; it is a diaphragm-type back pressure valve used to regulate upstream pressure. When the internal system pressure exceeds the user-preset opening point, the SR7 precisely opens to release or backflow, thus protecting valuable upstream equipment from overpressure damage. Its pressure control sensitivity is extremely high. It uses a 316L stainless steel body and a Hastelloy diaphragm, with a CV value of 0.08, making it ideal for installation at the end of process control loops and gas analysis sampling systems as a pressure-stabilizing bypass. In laboratory automation systems, the addition of the SR7 effectively constructs a closed-loop pressure control system and is an indispensable precision component for achieving constant pressure operation in gas flow paths.

  • Description
  • Contact Us

Series

Body Ports

Outlet Pressure

Inlet connector

Outlet Connector

Options

SR7

A

G

00

P

00

SR7L

(316L)

SR7B

(Copper electroplating)

A

G:0-250psi

1:0-100psi

K:0-50psi

L:0-25psi

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8 "card sleeve connector

11: 1/4 "card sleeve connector

12: 3/8 "card sleeve connector

Other forms of connectors are available for selection

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8 "card sleeve connector

11: 1/4 "card sleeve connector

12: 3/8 "card sleeve connector

Other forms of connectors are available for selection

P: Panel installation
