SR5 Series stainless steel two-stage pressure regulator

The SR5 cleverly integrates two pressure-reducing chambers into one unit, employing a two-stage diaphragm pressure-reducing structure to completely solve the problem of "inlet pressure fluctuation" inherent in single-stage pressure reducers. As the gas in the cylinder gradually depletes and the pressure continuously decreases, the SR5's two-stage compensation mechanism ensures a consistent output pressure. The product features a clear dual-dial display that simultaneously monitors both inlet and outlet status. The main body is available in 316L stainless steel or copper-plated materials to meet different budget and operating conditions. Its weight of 1.4kg is lightweight for a two-stage structure, ensuring structural strength while facilitating panel installation within confined analytical cabinets.

  • Description
  • Contact Us

Series

Body Ports

Inlet Pressure

Outlet Pressure

Gauge

Inlet connector

Outlet Connector

Options

  SR5

M

D

G

G

00

00

P

SR5L

(316L)

SR5B

(Copper electroplating)

M

Q

D:3000psi

F:500psi

G:0-250psi

1:0-100psi

K:0-50psi

L:0-25psi

Q:30"HgVac-30psi

S:30"HgVac-60psi

T:30"HgVac-100psi

U:30'HgVac-200psi

G: MPa table

P: Psi/bar table

W: No pressure gauge

00:1/4"NPT(F)

01:1/4"NPT(M)

23:CGA330

24:CGA350

27:CGA580

28:CGA660

30;CGA590

52:G5/8'-RH(F)

63:W21.8-14RH(F)

64:W21.8-14LH(F)

Other forms of connectors are available for selection

00:1/4"NPT(F)

01:1/4"NPT(M)

10: 1/8 "card sleeve connector

11: 1/4 "card sleeve connector

12: 3/8 "card sleeve connector

15: 6mm card sleeve connector

16: 8mm card sleeve connector

74;M8x1RH(M)

Other forms of connectors are available for selection

P: Panel installation

R: Safety valve

N: Needle valve

D: Diaphragm valve
